DC Power Supply (DC-PSU)
SIGLENT: DC POWER SUPPLY (DC-PSU)
- SIGLENT offers several series of DC power supplies, including linear models for high precision and low noise; switching models for higher power output. Independent, Series and Parallel mode connection are available for multiple outputs power supplies. Remote sensing (4-wire) is also available with up to 1V compensation.
- SPD-X Series: Linear DC power supplies designed with low ripple, low noise, high resolution that are applicable for educational, R&D, and production testing.
- Multiple Protection Modes: At least one or more protection modes; Over Current Protection (OCP), Over Voltage Protection (OVP), Over Temperature Protection (OTP), Limited Power Protection.
- Accessories SPD3000-RMK 4U Rack Mount Kit for SPD3000X Series
Refer to Selection Guide below
| MODEL | NO. OF CHANNELS | OUTPUT RATING | TOTAL POWER |
|---|---|---|---|
| SPD1000X | 1 | SPD1168X: 16V/8A SPD1305X: 30V/5A |
128W 150W |
| SPD3303C SPD3303X |
3 | CH1 & CH2: 32V/3.2A CH3: 2.5V,3.3V,5V/3.2A |
220W |
| SPD4000X | 4 | SPD4323X: 6V/3.2A, 32V/3.2A, 32V/3.2A, 6V/3.2A SPD4121X: 15V/1.5A, 12V/10A, 12V/10A, 15V/1.5A SPD4306X: 15V/1.5A, 30V/6A, 30V/6A, 15V/1A |
240W 285W 400W |
| SPS5000X | 1 to 3 | Programmable Switching DC Power Supply No. of Output Channels: 1 to 3 Rated Output Voltage: 40V, 50V, 80V, 160V |
180W 360W 720W 1080W |
| SPS6000X | 1 | Programmable Switching DC Power Supply SPS6225X: 200V/25A SPS6150X: 100V/50A |
1500W |
DC-PSU Datasheet Download:
